ATV400-D
ATV400-D
Share:
ATV400-D
  • VEHICLE
  • SPECIFICATION
Color
  • RED
  • BLACK
  • WHITE
  • GREEN
  • orange
  • BLUE
Detail
MODEL ATV400-D
Size: L×W×H 2100×1140×1270 mm
Wheelbase 1270 mm
Ground clearance 270 mm
Dry weight 330 kg
Loading capacity 129 kg
Fuel Tank Capacity 14 L
Max speed >70 km/h
Specification of tire Front: AT25×8-12
Rear: AT25×10-12
Brake system control model Front: Hand brake, Foot brake
Rear: Hand brake, Foot brake
Brake system model Front: Disk brake
Rear: Disk brake
Suspension type Front: McPherson independent suspension
Rear: Twin-A arms independent suspension
Engine type LH180MQ
Model Single cylinder,4 stroke, water cooled
Cylinder dimension 352 cc
Bore and Stroke 80×70 mm
Rated power 19/7000 (kw/r/min)
Max torque 27/5500  (Nm/r/min)
Compression Ratio 9.8:1
Fuel system CARB/EFI
Start type Electric starting
Transmission Automatic L-H-N-R
Loading quantity(40'HQ) 30
